Scott 2024 Foil RC PRO HMX Disc Frameset

Description

SCOTT frame set Road Foil RC PRO HMX | 2024

For everyone who values pure speed above all else, Scott has created the RC Pro series. With it you have the necessary equipment to push all boundaries and achieve victory after victory. No matter whether you're fighting against time or directly against the competition, you have the advantage.

The Foil RC PRO HMX comes with an eye-catching design for the 2024 model year. It still has a number of features that make it the ultimate race weapon. There are the HMX carbon fibers, the aerodynamic shape and the massive fork.

The HMX carbon fibers in particular contribute to the low weight and yet high rigidity. These are manufactured exclusively for Scott and come very close to the ideal situation between weight, stiffness and comfort. Particularly critical and stressed areas are additionally reinforced.

Aerodynamically, the foil has always played in a league of its own. The streamlined shape starts with the fork and continues consistently to the rear triangle. Nothing should be unnecessarily exposed to the wind and impair your propulsion. For example, the brakes are mounted close to the frame to prevent unnecessary turbulence. The close position of the rear wheel on the seat tube achieves the same thing. The elongated, solid-looking head tube allows the air to slide past undisturbed and the seat post clamp is integrated almost invisibly. Everything seems well thought out.

The clean look is achieved by ICCR cable routing, in which all cables and lines run through the frame. All conceivable constellations were considered. You can install both mechanical and electronic switching groups. The cables are routed neatly through inserts into the frame and are well protected from dirt and rain.

The set already includes a Scott Foil fork, the Syncros Carbon Aero seat post and an integrated headset from Acros. Everything has been color-matched to the frame and results in a uniform appearance that is guaranteed to be the envy of you.

Technical data:

intended use : racing bike, triathlon
Frame sizes: S, M, L, XL
Frame material: HMX Carbon
Fork material: HMX Carbon
Wheel size: 28" Road
Head tube: 1 1/8"-1 1/4", integrated
Seat tube (inner diameter): kA
Seat tube (outer diameter): kA
Bottom bracket standard: Pressfit PF 41 / BB86
axle type fork: 12 x 100mm thru axle
axle type frame: 12 x 142 mm thru axle
Front disc brake mount: Flat Mount
Rear disc brake mount: Flat Mount
Max. brake disc size: 160 mm
Switching type: mechanical or Di2
Front derailleur attachment: braze on
Cable routing: internal
Max. system weight: 120 kg (driver including clothing and possibly luggage)
maximum tire width: n/a
Feature:-
Color: matt silver with black-green decals

Weight frame according to the manufacturer: 985g
Weight frame weighed:
Weight fork according to the manufacturer: 475g (with unshortened shaft)
Weight fork weighed:
